GE(One-Piece Lamp Head) Halogen Machine Lamp
1.Waterproof Lighting
   Head :
Highly enclosed features, waterproof lighting head, tempered glass, and Teflon wires, avoid any water or oil entering into the illumination head, which enables Eminent Main lamps ideally used on a machine where powerful lubricant or cooling liquid is applied. (See Picture 001)
2.Superior Lighting
   Performance :
Halogen lamp and low voltage circuit each assures of high illuminance and safety.
3.Study Construction : The entire unit is extruded from aluminum material, anode treated for scratch prevention. The elbow and base are made of engineering plastic, durable and well resistant to electric shock and high temperature. Extremely light in weight.
4.Heat Dissipation : A brand-new design with high ribs aluminum alloy offers a high efficiency of heat dissipation and extends bulb service life. (See Picture 010)
5.Convenient Bulb
   Replacement :
With M4 screw for lens-holder, easy to tighten instead of breaking down.
6.Convenient Adjustment: Multi-position swiveling base constructed of steel ball and articulated arms permit positive and convenient adjustment to any lighting direction. (See Picture 005) Various arm lengths are available. In order to adjust arms more flexible, GE40 series added to selection (see Picture 005-1).
7.Upon request : Lamp without switch is available upon request. (See Picture gencw-2)
8.Elegant Appearance : The smooth, slim-line, and classic appearance will create elegant visual effect on your machine tool, or attractive tone in your home or office. Various mounting methods.
9.Supply Voltage : 12V or 24V. Safety class: III
10.Choices of Supply
     Voltage :
With built-in electronic transformer (See Picture 007) suited for 120V/230V. Safety class: I. Separate transformers are available.
11.Louver : The optional aluminum louver in front of head limits the angle of light¡¦s illuminating and prevents direct glare. Bring the soft illuminance to make eyes comfortable. (See Picture 011)
12.Quality Guarantee : CE and more.
13.Enclosure Type : IP65
